MMCX RF coaxial connector

Certificate
0
Commend
1





Item Number
MMCX-KE-2

Description

The series of MMCX radio frequency joining device is a kind of microminiaturized product smaller than MCX. It is small, light, joins convenient and reliable. Use for to system volume, serious to have small-scale communication, network equipment that require join the coaxial cable of the radio frequency extensively.


Features


Main feature:

Main technical characteristics:
Temp.range: -55~+155'C
Impedance: 50Ω
Frequency Range: DC~6GHz
Working Voltage: 170V max
Withstand Voltage: 500V rms
Contact resistance:
Center Contact: ≤ 5 mΩ
Outer Contact: ≤ 2.5 mΩ
Insulation resistance: ≥ 1000 MΩ

V. S. W. R:
Straight: ≤1.15
Right angle: ≤1.25
Durability(mating): ≥500 cycles


Material & plating:
shell: brass plated by nickel
contact pin: brass plated by gold or silver
socket: beryllium plated by gold or silver
elastic contact: beryllium plated by gold
insulator: PTFE
crimping suite: copper alloy plated by nickel
o-ring sealing: 6146 silastic

Applicable standard: CECC   22340
